Electronic overload relay (EOL) is the most compact, highfeatured, economical product in its class. Designed on a global platform, the new EOL covers the entire power control spectrum including NEMA, IEC and DP contactors. The NEMA and DP versions are offered with the C440 designation while the IEC offering has the XT designation. The electronic design provides reliable, accurate and value driven protection and communications capabilities in a single compact device. It is the flexible choice for any application requiring easy-touse, reliable protection.
|Brand Name||Eaton||Item Name||Electronic Overload Relay|
|Type||Electronic Overload Relay||Contact Configuration||1 NO - 1 NC|
|Series/Model||XTOE||Amperage Rating||20 - 100 A|
|Mounting Type||Direct||Dimensions||7-1/2 x 3-1/4 x 6-1/2 in|
|For Use With||NEMA, IEC and DP Contactors||Standards||CSA Certified, IEC 60947, EN 60947, UL Listed, RoHS Compliant, CE Certified, ATEX Compliant|
|Application||Commercial, Institutional Buildings, Structures||UPC||786685416571|
